Version 1.0 2013 IC-MXIC3B-01 Copyright by Indoorcycling Group GmbH 2013
|
www.indoorcycling.com ENG 26
Spare Part No. Description
Flywheel
FW HUB 1x
SELF TAPPING SCREW 4 x 12mm, STEEL, DIN EN ISO 6x
BALL BEARING, 6001 2z, 28mm x 12mm x 8mm 4x
FW PLASTIC COVER LEFT AND RIGHT 2x
FW PULLEY LOCK RING 1x
POLY V PL4 FW HUB PULLEY 1x
FW COVER DECAL SET 1x
FLYWHEEL 1x
SELF LOCKING NUT, M12 x 1.0P, STEEL, DIN985/ ISO10511 1x
WASHER, 24mm x 13mm x 2.5mm, STEEL, DIN125 / ISO 7089 1x
SERRATED LOCK WASHER, 20.5mm x 12.5mm x 1.0mm, STEEL,
DIN6798 1x
FW AXLE DISTANCE SLEEVE, LEFT SIDE (39mm) 1x
SELF LOCKING NUT, M12 x 1.0P, STEEL, DIN985/ ISO10511 1x
WASHER, 24mm x 13mm x 2.5mm, STEEL, DIN125 / ISO 7089 1x
SERRATED LOCK WASHER, 20.5mm x 12.5mm x 1.0mm, STEEL,
DIN6798 1x
FW AXLE DISTANCE SLEEVE, RIGHT SIDE (17mm) 1x
ALLEN BOLT, M8 x 50 x 1.25P, 8.8 STEEL, DIN912/ISO4762 1x
NUT, M8 x 1.25P, 8.8 STEEL, DIN934/ ISO4032 1x
BOTTON HEAD BOLT, M6 x 16 x 1.0P, STEEL, DIN7346/ ISO7380 2x
LOCKING PLATE FOR FW BRACKET 1x
FL PULLEY LOCK RING 1x
POLY V PL4 FW HUB PULLEY 1x
Frame INLAY SLEEVE HB TUBE
INLAY SLEEVE SEATPOST TUBE
DECAL - WARNING LABEL 1x
DECAL MX - FRONT FORK BADGE 2x
DECAL TRIBAL - FRONT COVER - TRANSFER BADGE 1x
DECAL IC3 - SEAT POST TUBE - ALUMINIUM BADGE (LEFT) 1x
DECAL IC3 - SEAT POST TUBE - ALUMINIUM BADGE (RIGHT) 1x
POP PIN ADJUSTMENT KNOB
