LCD Console
The LCD console can be purchased and used with the ICR50 cycle. An RF sensor that comes with the console will need to
be installed in the frame.
Console Overview
Use the console buttons to navigate through the console.
A. WORKOUT TRACK
• Solid = In-progress RPM workout
• Blinking = Goal to achieve (Program 2 only)
B. TARGET / RPM
• Program 1: Resistance target level
• Program 2: Current RPM
• Program 3: HR target
C. WORKOUT PROGRAMS
• Select by pressing at standby page
D. DISTANCE
E. CALORIES / SPEED
• Press to switch
F. HEART RATE
G. WORKOUT TIME
H. GOAL ACHIEVEMENT
• Light will illuminate once goal is achieved
I. WIRELESS HEART RATE CONNECTION
J. WORKOUT DATA
• To see AVG & MAX workout data, press: to
pause to switch calories / speed to switch AVG /
MAX
K. BATTERY
• Indicates 100% or less, 70% or less, 40% or less,
and 10% or less
