Matrix M1YL-LZ-210 User Manual

16
51 Screw M5X20 1
52 Nut M5 1
53 Upper Arm 1
54 UpperArm Lock Pin 1
55 O-Ring 5X1.8G 1
56 Brand Label 1
57 UpperArm Lock Button 1
58 Flat Washer Ø10 1
59 Nut M10 1
60 Lower Handle 1
61 Cable Holder 1
62 Screw M5X12 1
63 Cable Sleeve 1
64 Terminal Block 1
65 Screw M5X12 1
66 Spring Washer Ø5 1
67 Flat Washer Ø5 1
68 Upper Handle 1
69 Screw M5X35 2
70 Spring Washer Ø5 2
71 Flat Washer Ø5 2
72 Tapping Screw ST4.2x16 5
73 Lever lock 1
74 Trigger 1
75 Spring 1
76 ON-OFF Switch 1
77 Ball Bearing 6200 1
78 Shaft Lock Bar 1
79 Armature 1450w 1
80 Ball Bearing 608 1
81 Bearing Bush 1
82 fan shroud 1
83 Tapping Screw ST4.2x65 2
84 Stator 1450w 1
85 Motor Housing 1
86 Carbon Brush Cover 2
87 Carbon Brush 2
88 Carbon Brush Holder 2
89 Brand Label 1
90 Screw M5X30 4
91 Spring Washer Ø5 4
92 Flat Washer Ø5 4
93 Needle Bearing 1
94 Screw for Lower Guard
Stationery Plate
1
95 Gearbox Assembly 1
95.01 Spring Ring Φ12 1
95.02 Gear 1
95.03 Flat Key 4x4x10 1
95.04 wave washer Ø12 1
95.05 Bearing Seat 1
95.06 Ball Bearing 6002 1
95.07 Output Spindle 1
95.08 Bearing Cover 1
95.09 Screw M4X8 3
96 Screw M5X40 2
97 Flat Washer Ø6 2
98 Nut M5 1
99 Flat Washer Ø8 1
100 Lock Washers 1
101 Flat Washer Ø5 2
102 Screw M5X8 2
103 Caging Knob 1
