42
PORTUGUÊS
Z12x8
Z08x8
Z04x4
Z07x8
Z10x4
Z07x8
Z11x 8
Z09x2
Z07x2
Z07x4
Z11x4
2
Hardware Qtd.
Z09
Z07
Z11
Parafuso (M10x75L)
Arruela plana (M10x25L)
Parafuso (M10x30L)
2
14
12
MONTAGEM
1
Hardware Qtd.
Z08
Z07
Z10
Z04
Z12
Parafuso (M10x25L)
Arruela plana (M10x25L)
Parafuso (M10x105L)
Porca (M10)
Arruela plana (M10x19L)
8
8
4
4
8
MONTAGEM CONCLUÍDA
