CHAPTER 6: MX-T3X / T3Xi TreaDmill specifications, parts, anD assembly guiDes
MX-T3X / T3XI • TREADMILL
6.2 MX-T3X / MX-T3XI MODEL REqUIRED FASTENERS & ASSEMBLEY TOOLS
08 Z51 SOCKET HEAD CAP SCREW M10 x 25
01 8mm ALLEN WRENCH
01 10mm ALLEN WRENCH
02 Z52 BUTTON HEAD MACHINE SCREW M5 x 12L
08 Z50 FLAT WASHER 30x2.0L
QTY PART # SKETCH DESCRIPTION NOTES
01 #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ]
04 Z52 SOCKET HEAD CAP SCREW M8 x 30
