CHapter 7: MX-t4x / MX-t5x treadmill SpecificationS, partS, and aSSembly GuideS
7.2 MX-t4X / MX-t5X Model required fasteners & asseMbley tools
08 C09 FLAT HEAD MACHINE SCREW (M8 x 25L)
01 Z12 5mm ALLEN WRENCH
01 Z13 4mm ALLEN WRENCH
01 Z09 ALLEN WRENCH [ #8 x 168 ]
04 C24 BUTTON HEAD MACHINE SCREW (M5 x 10L)
04 C11 SOCKET HEAD CAP SCREW (M5 x 20L)
04 Z50 FLAT WASHER (
14 C10 FLAT HEAD MACHINE SCREW (M8 x 20L)
QTY PART # SKETCH DESCRIPTION NOTES
01 Z10 ALLEN WRENCH [ #5 x 172 ]
01 Z08 #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ]
5.2 x 12 x 1.0t)
MX-t4X / MX-t5X • treadMill
