17
Operating mode S1 (continuous operation)
The machine can be continuously operated with
the quoted power output.
Operating mode S2 (temporary operation)
The machine may be temporarily operated
with the quoted power output. Afterwards the
machine must be stopped for a while to prevent
it from overheating
Engine
Engine design:
Forced Air-Cooled, 1-Cylinder, 4-Stroke, OHV
Spark plug: TORCH A7RTC
Displacement: 79.7 cm
3
Fuel type: unleaded petrol
Tank capacity: 4,0 L
Engine oil: Appox.0.35 l (15W40/<0 °C: 5W30)
Weight: 21.5 kg
Guaranteed sound power level L
WA
: 92 dB(A)
Max. Temperature: 40 °C
Max. Altitude (above mean sea level): 1000 m
5. Parts Layout
1. Fuel tank cap air vent knob
2. Fuel cap
3. 230 V~ socket outlets
4. 12 V d.c. connector outlets
5. 12 V d.c. circuit breaker
6. Warning lights
7. Earth connection
8. ECS switch
9. Oil filler plug
10. Air filter set
11. Engine switch
12. Pull cord
13. Oil filling funnel
14. DC connecting cord
15. Spark plug wrench
16. Screw driver
17. Spark plug
18. Fuel Cock Knob
19. Choke Knob
20. Oil Level Indicator
as well as the time span in which the operator
is subjected to the noise. Also, the permitted
emission level can vary from country to country.
Nevertheless, with this information the user is
able to make a better assessment of the dangers
and risks involved.
CAUTION: Read all safety regulations and
instructions.
Any errors made in following the safety
regulations and instructions may result in an
electric shock, fire and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
3. Proper Use
The generator is intended to provide electric
tools, light sources and household appliances.
When using the device with precise equipments,
please check their suitability in accordance
with the relevant manufacturer’s instructions.
In case of doubt, ask an authorized dealer of
the respective appliance. The machine is to be
used only for its prescribed purpose. Any other
use is deemed to be a case of misuse. The user /
operator and not the manufacturer will be liable
for any damage or injuries of any kind caused as
a result of this.
The device is designed for applications operated
with a 230 V alternating current source for 230 V.
4. Technical Data
Generator
Generator type: Inverter
Ingress Protection: IP23M
Rated voltage Urated: 2X230 Va.c. / 12V d.c.
Continuous rated power Prated (S1): 1,7 kW
Maximum power Pmax: 1,88 kW
Frequency Frated: 50 Hz
Power factor: Cosφ=1
Performance class: G1
UK
