47
• Remove the air cleaner from the carburetor and
clean it with soap and water thoroughly. Rinse
and dry thoroughly. Put a few drops of oil on the
air purier and distribute it. Mount the air cleaner
again.
• Store the device in a clean, dust-free location.
Caution!
Do not remove the D-shaped shim from the
clamping of the gearbox housing! The shim
prevents damage caused by excessive tightening
of the clamping screw.
1. Loosen the clamping screw of the gearbox
housing.
2. Remove the index screw from the gearbox.
1
A56
3. Pull the gearbox out of the tube. Use a grease
gun and pump lithium grease (about 10 g) into
the lubricating hole of the gearbox until old
grease comes out of the gearbox (A 56). This
grease exits into the cavity of the outer tube.
Remove excess grease and put the gearbox
housing into the outer tube. Make sure that the
index screw is snapped into the outer tube lock.
Tighten both screws.
