Matrix S7xi - Page 13

13
6
Z01
Z02
Z02
Z01
Z02
Z01
LOCK WASHER Qty: 8
SOCKET HEAD BOLT(M8x16L) Qty: 8
ASSEMBLY STEP 2
A Open WHITE HARDWARE BAG.
B Attach MANUAL INCLINE LIFT LEVER to GUIDE
RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS
(E), 4 SPRING WASHERS (F) and 4 NUTS (G).
C Align GUIDE RAIL SET with MAIN FRAME as
shown.
D Lift up on the MANUAL INCLINE LIFT LEVER
and place it in one of the holes inside the MAIN
FRAME.
E Attach the GUIDE RAIL SET to the MAIN FRAME
using 4 BOLTS (G), 4 FLAT WASHERS (H), 4
SPRING WASHERS (I) and 4 NUTS (J).
WHITE HARDWARE BAG CONTENTS
