27
ASSEMBLY STEP 2
A Open hardware bag 2.
B With the console upside down, attach the
console mast caps to the console
using 4 bolts (e) and 4 spring
washers (b).
11
SOCKET HEAD CAP SCREW
Qty: 8
12
FLAT WASHER
Qty: 8
BLUE HARDWARE BAG CONTENTS :
NOTE: The console mast caps are marked with an
L if they are to be used on the left-hand side of the
treadmill or an R if they are to be used on the right-
hand side of the treadmill. If the console mast caps
are assembled on the incorrect side of the treadmill,
the unit will not assemble correctly.
12
11
To Next Page
