11
Indicates if Console is commanding speed. LED 11PWM
Indicates the motor is moving via the encoder's
feedback by blinking.
LED 12SPEED
Indicates if the upper console is commanding Elevation
UP.
LED 10UP
Indicates if the upper console is commanding Elevation
DOWN.
LED 9DOWN
Indicates if the DSP Power Supply is present. LED 8VDSP
Indicates if Console Voltage Supply is present. LED 7+VCON
Indicates if the DC Buss is Energized (Voltage Present). LED 6AC
Main Status/Error LED. LED 5
Auxiliary Status LED/Digital to Analog Output. LED 4
Auxiliary Status LED LED 3
Auxiliary Status LED LED 2
Auxiliary Status LED LED 1STATUS
Description
Reference
Designator
LED
NORMAL OPERATION
1. LEDs 1, 2 and 3 Sequence back and forth to indicate the processor is on-
line and operational.
2. LED 4 is used as a discrete/analog signal to the upper console.
3. LED 5 indicates system status/mode. Currently 3 modes are defined safe
mode, stand-by mode and run mode. They are defined as follows:
a) Safe Mode - When the controllers safety relay is not energized and no
error exists, LED 5 remains off.
b) Stand-by Mode - When the safety relay is engaged but the system is not
outputting an active PWM to the motor and no error exists, LED 5 blinks off
and on at a fast rate.
c) Run Mode - When the system outputs an active PWM Control signal to
the motor and no error exists, LED 5 remains ON.
To Next Page
