Matrix T4x User Manual

29
E9 – Speed Range Error
OVERVIEW
During normal run time operation the value stored during auto calibration is used to
initially set the speed (e.g. target speed = 12 MPH, PWM ticks = Maximum PWM =
363). Once the speed stabilized the actual speed is monitored and if different than
the target speed the PWM value is adjusted until the actual speed matches the
target speed. If the PWM value is changed by more than the amount of ticks
required to change 0.8 MPH and the actual speed does not match the target speed
then an E9 error is flagged. This error indicates the motor controller system is
unable to maintain the target speed.
N
Y
N
Y
N
Y
E9 Error
Before cycling power inspect
the motor controller for error
Motor
controller error
Start PWM half test and
allow 20 seconds for belt to
start moving
Measure speed and
compare to value
displayed in time window
OK
Perform steps outlined in
speed feedback issue
Run Auto Calibration
Error
Gone
Perform steps outlined in
speed control issue
Done
Record the
error code
from the motor
controller
Check for free
movement of
belt roller
movement
Cycle
Power
Run auto
calibratio
n
Done
