Matrix T4x User Manual

34
Speed Calibration Issue
Run auto calibration (firmware setup
screen)
N
Y
Auto calibration
passed
Done
Start PWM max test (firmware setup
screen), wait minimum 20 seconds or
until sped stabilizes
Measure speed and compare to value
displayed in time window
N
Y
OK
Check speed feedback
issue
Check speed control issue
CORRECTIVE ACTION PROCEDURES – Speed Calibration Issue
