Matrix VS-S33 Lat Pulldown - Parts List; Standard Components

8
Parts List
ID
DESCRIPTION
QTY
1 User Frame 1
2 Weight Stack Frame 1
3 M10 X 105L SHC 2
4 Narrow Cupped Flange 1
5 M10 Flat Washer 14
6 M10 Nylock Nut 4
7 Upper Connecting Tube 1
8 M10 X 20L SHC 6
9 M10 X 125L SHC 2
10 Wide Cupped Flange 1
11 Lower Connecting Tube 1
12 Thigh Pad Assembly 1
13 Pullpin Assembly 1
14 M8 X 150L SHC 1
15 Axle 1
16 M8 Flat Washer 6
17 M8 Nylock Nut 1
18 Large Flat Washer (Ø40 mm) 2
19 Belleville Washer 2
20 Right Arm Assembly 1
21
M10 X 25L SHC 2
22 Left Arm Assembly 1
23 M12 X 25L Socket Head Cap Screw 2
24 M12 Flat Washer 2
25 Weight Stack to User Frame Cable 1
26 User frame Cable 1
27 Counter Weight 2
28 M8 X 20L Socket Head Cap Screw 4
29 M10 X 20L Hex Bolt 4
30 Pad 1
31 Front Shroud 1
32 Rear Shroud 1
33 M8 X 25L Socket Head Cap Screw 4
34 M8 Flat Washer (Ø20 mm) 4
35 Top Cap 1
36 Top Cap Covers 2
