24 Matrox TripleHead2Go – User Guide
4 Connect the first monitor
Connect the DVI connector on your
monitor cable directly to the first connector
() on your Matrox product.
5 Connect the second monitor
Connect the DVI connector on your
monitor cable directly to the second
connector ( ) on your Matrox product.
6 Connect the third monitor
Connect the DVI connector on your
monitor cable directly to the third connector
() on your Matrox product.
Your Matrox product is now connected. Restart your computer and install your Matrox software (see
“Installing your Matrox software”, page 32).
Monitor cable
(DVI)
Monitor cable
(DVI)
Monitor cable (DVI)
