CONVENTIONAL HEAVY DUTY RELAY
The MPVSR can be used as a conventional heavy duty relay for switching
loads up to 150Amps continuous current at 12VDC. The control device
is wired in series with the control wires and activated as required. The
voltage settings should be programmed out of any range that would affect
operation. Also, the relay can be set to either normally closed or normally
open depending on requirements.
CONVENTIONAL HEAVY DUTY RELAY WIRING
EXAMPLE
LOAD
150A
MAX
CONTROL
SWITCH
