8
The machine doesnt run
Is the machine plugged in and the mains supply on?
Is the room temperature within the working range of the
unit (16 C - 32 C)?
The machine is very noisy
Is the floor underneath the unit uneven? Make sure all
four castors are positioned flat against the floor.
The compressor isnt running
Is it possible that the overheat protection of the compressor
is on? Turn the unit off. Wait a few minutes for the
temperature to cool and turn on again.
The machine is running but not cooling the room
If the sun is shining directly into the room, close the curtains.
Ensure the windows and doors are closed.
Is there something in the room producing heat?
The machine is on but doing very little
Are the filters dusty or need cleaning?
Is the room temperature below your selected temperature?
Other abnormal conditions
Disconnect from the mains supply and consult a
repair specialist.
o
o
SPECIFICATIONS
Power supply: 230-240V
Cooling capacity: 9000/2600BTU/Hr
Air voulme (max speed): 430 m /h
Power input: 1200W
Refigerant type: R-410A
Refrigerant load: 550g
Recommended room size: up to 24m
Duct length: 2m
Cooling range: 16 C - 32 C
Net weight: 31Kgs
Dimension: 840HX450WX370Dmm
3
2
o
