Product Overview
Main Unit
1110
6 8
7
129
12 13
9 10
11
13
2
3
4
5
1
Control Panel
Remote Control
1. Control Panel
2. Tower Fan
3. Front Base
4. Rear Base
5. Base Clip
6. Timer Indicator
7. Mode Indicator
8. Speed Indicator
9. Swing Button
10. Timer Button
11. Wind Type Button
12. Speed Button
13. ON/OFF Button
