10
To activate each appliance, simply press the corresponding on / off button on the front of
the Switch Box, labelled:
For more detailed programming instructions (for the Switch Box Timer) see page 11.
TYPICAL EXAMPLE OF A COMPLETE INSTALLATION
PUMP LIGHTS FEEDER SKIMMER
POWER
IN
UV
PUMP LIGHTS FEEDER SKIMMER
POWER
IN
UV
ACTIVATING CONNECTED APPLIANCES (SWITCH BOX ONLY)
