vertical fin in position with the two
2.6 x 35mm screws provided, (image
D). The screws must be tightened
sufficiently to securely fix the parts
in position, however be careful not
to over-tighten the screws.
snap-links to their respective control
horns as shown in images E & F.
Minor adjustment to obtain perfect
neutral positions of the control
surfaces can be achieved by rotating
the plastic link on the threaded
portion of the control push-rod.
Make certain the plastic link is
securely “snapped” closed when
connected to the control horn.
