Maxatec MT-200E - Specifications; General Specifications; Auto Cutter Specifications; Interface

18
19
9. Specifications
Appendix A : Specifications
9-1. General Specifications
(1) Printing Method Direct line thermal printing.
(2) Print speed 200mm/sec
(3) Dot density
180 DPI (Hor / Ver) 180 / 180 (0.142mm / 0.142mm dot)
(4) Printing Width
180 DPI Max 72mm (512 dots)
(5) Number of print columns.
No. of columns
Font “A” Font “B”
180 DPI 42 56
(6) Roll paper Refer to chapter 2 for details on the recommended roll Paper.
Paper width : 50mm~82.5mm
Roll diameter : Max. Ø80mm
(7) Weight 3.75 lbs (1.7Kg)
(8) Overall dimension
9-2. Auto Cutter Specifications
(1) Cutting Frequency Max. 30 cuts per minute
(2) Thickness of paper 0.06 ~ 0.09 mm
(3) Cutter Life 1.5 million cuttings
9-3. Interface
RS232 Serial Interface, Centronics Parallel Interface(IEEE1284), USB Interface,
Ethernet Interface(100Mbps)
9-4. Electrical Characteristics
(1) Input Voltage DC 24V ± 10%
(2) Current Consumption Operating: Approx. 1.5 A (at ASC∥printing)
Peak : Approx. 10 A
(at print duty 100%, For 10 seconds or less)
Stand-by : Approx. 0.03 A
(3) Power Connector
