Table of Contents
1. Parts Identifications
PRINTER COVER
POWER SWITCH
COVER OPEN LEVER
CONTROL PANEL
Open this cover to
load or replace paper.
Used to turn on/off
power to the printer.
Pull down this lever to
open the printer cover.
Features LED indicators
to indicate printer status
and switches to operate
the printer.
INTERFACE CONNECTOR
PERIPHERAL DRIVE CONNECTOR
POWER CONNECTOR
INTERFACE CONNECTOR (USB)
1. Parts Identifications 3
2. Setting up the printer 4
2.1 Unpacking 4
2.2 Connecting the cables 5
2.3 Loading the roll paper 9
2.4 Adjustment of paper width 12
3. Control panel and other functions 13
3.1 Control panel 13
3.2 Error Indicating 13
4. Self Test 14
5.
ASCII Print
15
6.
Select Baudrate Mode
15
7. Hexadecimal Dump 16
8. Printer cleaning 17
9. Specifications 18
9.1. General Specifications 18
9.2. Auto Cutter Specifications 19
9.3. Interface 19
9.4. Electrical Characteristics 19
9.5. Environmental Requirements 20
9.6. Reliability 20
9.7. Certification 20
10. Command List 21
