Maxell MP-EU5002 - Page 6

6
QM00062-1
Connection to the ports (continued)
G
AUDIO IN1
H
AUDIO IN2
Ø3.5 stereo mini jack
NWHUPLQDWRU
AUDIO IN3
I
R,
J
L
RCA jack x2
NWHUPLQDWRU
K
AUDIO OUT
Ø3.5 stereo mini jack
NRXWSXWLPSHGDQFH
D
HDMI1
E
HDMI2 / MHL
F
HDMI3
• Type :Digital audio/video connector
• Audio signal : Linear PCM (Sampling rate; 32/44.1/48 kHz)
Pin Signal Pin Signal Pin Signal
1
T.M.D.S. Data2
+N.C.
8
T.M.D.S. Data0 Shield
MHL_Shield
15
SCL
CD_PULLUP
2
T.M.D.S. Data2 Shield
CD_SENSE
9
T.M.D.S. Data0 -
MHL-
16
SDA
N.C.
3
T.M.D.S. Data2 -
N.C.
10
T.M.D.S. Clock +
N.C.
17
DDC/CEC Ground
VBUS_CBUS_GND
4
T.M.D.S. Data1 +
N.C.
11
T.M.D.S. Clock Shield
TMDS_GND
18
+5V Power
VBUS
5
T.M.D.S. Data1 Shield
TMDS_GND
12
T.M.D.S. Clock -
N.C.
19
Hot Plug Detect
CBUS
6
T.M.D.S. Data1 -
N.C.
13
CEC
N.C.
7
T.M.D.S. Data0 +
MHL+
14
Reserved(N.C. on device)
N.C.
10 12 14 16 182468
911131517191357
D
I
E
G
H
J
K
F
