MENU 1-2 Zone Names
O Menu “Nomes de Zonas” allows you to customize the name of the zones
which are later shown on the display, making easier to find and
identification the source of the alarm or fault.
With one touch the “Ent / Esc”, enters on menu.
With Cursor keys “Left” and “Right” to select the zone to rename, confirming the selection with touch
the key “Ent / Esc”.
With the cursor keys “Up” and “Down” selects the characters to register in each position, advancing to
the positions with the cursor keys “Left” and “Right”.
You can select the uppercase or lowercase character by holding down the cursor key “Up” or “Down”,
during the selection of the corresponding character.
After the edition of name of the zone, press the button again “Ent/Esc”. Appears on the display the
message “Setting Saved”.
MENU 1-3 Confirmation
The Menu “Confirmation” allows to define “pairs” of zones which must be
ctuated so that the Control Panel recognize an alarm event.
This option is especially suitable for use in zones of false alarms high risk , or for integration with auto-
matic fire extinguishing.
The pairs of zones are set as described in Table 1 below:
Table 1
MENU 1-4 Sounder 1
The Menu “Sounder 1” lets you define which zones of the system that act
the output Sounder 1.
By accessing this menu, you can select zones that will trigger or not the
output.
As the cursor keys to select “Up” and “Down” appears on the display messages
“Trigger” or “Not Trigger”.
MENU 1-5 Sounder 2
The same menu setting 1-4, for the Sounder 2 output.
MENU 1-6 Alarm Relay
The Menu “Alarm Relay” lets you define which zones of the system that
act the Alarm Relay.
By accessing this menu, you can select zones that will trigger the relay.
As the cursor keys to select “Up” and “Down” appears on the display messages
“Trigger” or “Not Trigger”.
