MAXHUB XT10-WS Kit - Page 11

09
● Connection Diagram
① Complete the device connection according to the illustration, as shown in Figure 1.
② Press the Mini PC power button to start up, as shown in Figure 2.
Figure 1:
Figure 2:
Power
FOR CONSOLE
3.1
FOR DISPLAY
HDMI OUT
LAN
3.0 3.0
PERIPHERAL
AC POWER
USB DeviceDisplayTouch Control Panel
Network
