continued on next page
60
Removing Seat Pad Set
For Cleaning
59
You do not need to remove the harness system to remove
the pad from the shell.
To remove accessories, see pages 3-5.
Adjust Headrest to Highest
Position
Unbuckle Harness
Press in on red button and pull out
buckle tongues.
1
2
3
4
Fully Loosen Harness Straps
Push down on harness release lever
(through opening in pad) while pulling
out on harness straps as shown.
Undo Fasteners on Headrest
Pad As Shown
6
At the Back of the Headrest, Pull
the Fabric Tabs Out from Slots in
Headrest As Shown
Repeat for other side.
7
Gently Pull Headrest Pad Off
Bottom of Headrest As Shown
Remove headrest pad from shell.
8
Undo Fasteners on Seat Pad As
Shown
5
At the Headrest/Harness
Adjustment Handle, Pull the Fabric
Tab Out from Between the Headrest
and Headrest Foam As Shown
To Next Page
