Evaluates: MAX86140 and MAX86141
MAX86140/MAX86141
Evaluation System
MAX86140OSBEK#—BOTTOMMAX86140OSBEK#— L03_SIG
MAX86140/MAX86141 EV Kit PCB Layout Diagrams (continued)
MAX86140_OSB_EVKIT
