Maxim Integrated MAX86140 - MAX86140;MAX86141 EV Kit Bill of Materials

Maxim Integrated │ 20
www.maximintegrated.com
Evaluates: MAX86140 and MAX86141
MAX86140/MAX86141
Evaluation System
MAX86140/MAX86141 EV Kit Bill of Materials
MAXSENSORBLEEK#
ITEM REF_DES DNI/DNP QTY MFG PART # MANUFACTURER VALUE DESCRIPTION COMMENTS
1 A1 - 1 2450AT18A100 JOHANSON TECHNOLOGY 2450AT18A100
ANTENNA; 2450AT SERIES; BOARDMOUNT;
MINI 2.45 GHZ ANTENNA; 2450MHZ
2 BAT - 1 B2B-PH-K-S(LF)(SN) JST MANUFACTURING B2B-PH-K-S(LF)(SN)
CONNECTOR; MALE; THROUGH HOLE;
PH CONNECTOR; 2MM PITCH;
SHROUDED HEADER; STRAIGHT; 2PINS
3
C1, C22, C26,
C30-C37
- 11
GRM033R61A104KE15;
LMK063BJ104KP
MURATA;TAIYO YUDEN 0.1UF
CAPACITOR; SMT (0201); CERAMIC CHIP;
0.1UF; 10V; TOL=10%; MODEL=;
TG=-55 DEGC TO +125 DEGC; TC=X5R
4
C2, C15, C25,
C38-C43
- 9 GRM033R61A105ME15 MURATA 1UF
CAPACITOR; SMT (0201); CERAMIC CHIP;
1UF; 10V; TOL=20%; TG=-55 DEGC
TO +85 DEGC; TC=X5R
5
C3, C4, C8, C9,
C12, C16, C27
- 7 C1005X5R1A475M050BC TDK 4.7UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
4.7UF; 10V; TOL=20%; MODEL=C SERIES;
TG=-55 DEGC TO +85 DEGC; TC=X5R
6
C5-C7, C10,
C13, C14, C47
- 7 GRM155R60J226ME11 MURATA 22UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
22UF; 6.3V; TOL=20%; TC=X5R
7 C19 - 1 GJM0335C1E1R0WB01 MURATA 1PF
CAPACITOR; SMT (0201); CERAMIC CHIP;
1PF; 25V; TOL=0.05PF; TG=-55 DEGC
TO +125 DEGC; TC=C0G
8
C20, C21, C28,
C29, C45, C46, Z44
- 7 GRM0335C1H120GA01 MURATA 12PF
CAPACITOR; SMT (0201); CERAMIC CHIP;
12PF; 50V; TOL=2%; TG=-55 DEGC
TO +125 DEGC; TC=C0G
9 C23, C24 - 2 GRM0335C1H101JA01 MURATA 100PF
CAPACITOR; SMT (0201); CERAMIC CHIP;
100PF; 50V; TOL=5%; TG=-55 DEGC
TO +125 DEGC; TC=C0G
10 CN1 - 1 DX07S024JJ3 JAE ELECTRONIC INDUSTRY DX07S024JJ3
CONNECTOR; FEMALE; SMT; USB TYPE-C
CONNECTOR; DX07 SERIES RECEPTACLE;
RIGHT ANGLE; 24PINS
11 DS1, DS2 - 2 SML-P11UTT86 ROHM SML-P11UTT86 DIODE; LED; SMT; PIV=1.8V; IF=0.02A
12 J3 - 1 5035662500 MOLEX 5035662500
CONNECTOR; FEMALE; SMT; EASY-ON
TYPE HOUSING ASSEMBLY; RIGHT
ANGLE; 25PINS
13 L1, L2 - 2 DFM18PAN2R2MG0L MURATA 2.2UH
INDUCTOR; SMT (0603); CERAMIC CHIP;
2.2UH; TOL=+/-20%; 1.1A;
14 L3 - 1 DFE201610E-4R7M=P2 MURATA 4.7UH
INDUCTOR; SMT (2016); METAL ALLOY CHIP;
4.7UH; TOL=+/-20%; 1.3A
15 L4 - 1 LQP03HQ3N3B02 MURATA 3.3NH
INDUCTOR; SMT (0201); FILM TYPE; 3.3NH;
TOL=+/-0.1nH; 0.5A
16 LED - 1 SML-LX0404SIUPGUSB LUMEX OPTOCOMPONENTS INC SML-LX0404SIUPGUSB
DIODE; LED; SML; FULL COLOR;
WATER CLEAR LENS; RED-GREEN-BLUE;
SMT; VF=2.95V; IF=0.1A
17
R2, R3, R11, R15,
R24, R27-R31, R34
- 11 ERJ-2GE0R00X PANASONIC 0
RESISTOR; 0402; 0 OHM; 0%; JUMPER;
0.10W; THICK FILM
18 R5, R9 - 2 ERJ-1GEF1002C PANASONIC 10K
RESISTOR; 0201; 10K OHM; 1%; 200PPM;
0.05W; THICK FILM
19
R6, R7, R16, R17,
R23, R25, R26
- 7 ERJ-1GEF4701C PANASONIC 4.7K
RESISTOR; 0201; 4.7K OHM; 1%; 100PPM;
0.05W; THICK FILM 3-LAYER ELECTRODE
20 R8 - 1 ERJ-1GEF3902C PANASONIC 39K
RESISTOR; 0201; 39K OHM; 1%; 100PPM;
0.05W; THICK FILM 3-LAYER ELECTRODE
