Maxim Integrated
│
21
www.maximintegrated.com
Evaluates: MAX86140 and MAX86141
MAX86140/MAX86141
Evaluation System
MAX86140/MAX86141 EV Kit Bill of Materials (continued)
MAXSENSORBLEEK#
ITEM REF_DES DNI/DNP QTY MFG PART # MANUFACTURER VALUE DESCRIPTION COMMENTS
21 R10 - 1 NCP15XH103F03RC MURATA 10K
THERMISTOR; SMT (0402); THICK FILM
(NICKEL PLATED); 10K; TOL=+/-1%
22 R13 - 1 ERJ-1GEF2613C PANASONIC 261K
RESISTOR; 0201; 261K OHM; 1%; 200PPM;
0.05W; THICK FILM
23 R14 - 1 CRCW0201100KFK VISHAY DALE 100K
RESISTOR; 0201; 100K OHM; 1%; 100PPM;
0.05W; THICK FILM
24 R18, R19 - 2 ERJ-1GEF2000C PANASONIC 200
RESISTOR; 0201; 200 OHM; 1%; 200PPM;
0.05W; THICK FILM
25 RA1-RA4 - 4 ERJ-1GEF33R0C PANASONIC 33
RESISTOR; 0201; 33 OHM; 1%; 100PPM;
0.05W; THICK FILM 3-LAYER ELECTRODE
26 SW - 1 EVP-AWCD2A PANASONIC EVP-AWCD2A
SWITCH; SPST; SMT; STRAIGHT; 15V;
0.02A; EVP-AW SERIES
27 U1 - 1 MAX20303 MAXIM MAXIM SENSOR PLATFORM 2
EVKIT PART- IC; WEARABLE POWER
MANAGEMENT SOLUTION; PACKAGE
OUTLINE; WLP 56 PINS; 0.5MM PITCH;
PKG. CODE: W563A4+1;
PKG. OUTLINE: 21-100104;
28 U2 - 1 NRF52832-CIAA NORDIC SEMICONDUCTOR NRF52832-CIAA
IC; SOC; MULTIPROTOCOL BLUETOOTH LOW
ENERGY; ANT; 2.4GHZ RF SOC; WLCSP50
29 U3-U6, U9 - 5 MAX14689EWL+ MAXIM MAX14689EWL+
IC; ASW; 0.125A; FREQUENCY-SELECTSBLE;
SWITCHED-CAPACITOR VOLTAGE
CONVERTER; WLP9 1.2X1.2
30 U7 - 1 IP4221CZ6-S NXP IP4221CZ6-S
IC; PROT; ESD PROTECTION FOR
HIGH-SPEED INTERFACE; XSON6
31 U8 - 1 S25FS256SAGNFI001 SPANSION S25FS256SAGNFI001
IC; MMRY; MIRRORBIT FLASH; NON-VOLATILE
MEMORY; 1.8V SINGLE SUPPLY WITH
CMOS I/O; SERIAL PERIPHERAL INTERFACE
WITH MULTI-I/O; WSON8-EP
32 U10, U11 - 2 MAX9062EBS+G45 MAXIM MAX9062EBS+G45
IC; COMP; ULTRA-SMALL; LOW-POWER
SINGLE COMPARATOR; UCSP4
33 U12 - 1 MAX32620IWG+ MAXIM MAX32620IWG+
IC; UCON; HIGH-PERFORMANCE;
ULTRA-LOW POWER CORTEX-M4F
MICROCONTROLLER FOR RECHARGEABLE
DEVICES; WLP81
34 U13 - 1 74AUP1G97GF NXP 74AUP1G97GF
IC; LOGC; LOW-POWER CONFIGURABLE
MULTIPLE FUNCTION GATE; XSON6
35 U29 - 1 MAX1819EBL50+ MAXIM MAX1819EBL50+
IC; VREG; 500MA LOW-DROPOUT LINEAR
REGULATOR IN UCSP; UCSP6
36 X2, Y2 - 2 ECS-.327-6-12 ECS INC 32.768KHZ
CRYSTAL; SMT 2.0 MM X 1.2 MM; 6PF;
32.768KHZ; +/-20PPM; -0.03PPM/DEGC2
37 Y1 - 1 US3200005Z PERICOM SEMICONDUCTOR 32MHZ
CRYSTAL; SMT 1.6 MM X 1.2MM; 8PF;
32MHZ; +/-10PPM; +/-10PPM
38 PCB - 1 MAXSENSORBLE MAXIM PCB PCB:MAXSENSORBLE -
39 MISC1 DNI 1 101181XX-000XXX N/A 101181XX-000XXX
CONNECTOR; MALE; PALETTE SERIES 3.0
USB-C TO USB-A; 3FT BLACK
40
R1, R4, R12, R20-R22,
R32, R33
DNP 0 ERJ-2GE0R00X PANASONIC 0
RESISTOR; 0402; 0 OHM; 0%; JUMPER;
0.10W; THICK FILM
41 Z17 DNP 0 GJM0335C1E1R0WB01 MURATA 1PF
CAPACITOR; SMT (0201); CERAMIC CHIP;
1PF; 25V; TOL=0.05PF; TG=-55 DEGC
TO +125 DEGC; TC=C0G
42 Z18 DNP 0 250R05L1R8AV4 JOHANSON TECHNOLOGY 1.8PF
CAPACITOR; SMT (0201); MICROWAVE;
1.8PF; 25V; TOL=0.05PF; TG=-55 DEGC
TO +125 DEGC; TC=C0G
43 Jan-36 DNP 0 N/A N/A N/A
TEST POINT; PAD DIA=0.762MM;
BOARD HOLE=0.381MM
TOTAL 105
