Evaluates: MAX86140 and MAX86141
MAX86140/MAX86141
Evaluation System
MAX86140/MAX86141 EV Kit Bill of Materials (continued)
MAX86140OSBEK#
MAX86141OSBEK#
ITEM REF_DES DNI/DNP QTY MFG PART # MANUFACTURER VALUE DESCRIPTION COMMENTS
1
C1-C3, C5,
C6, C9
- 6 GRM155R60J226ME11 MURATA 22UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
22UF; 6.3V; TOL=20%; TC=X5R
2 C4, C8 - 2 GRM033R61A105ME15 MURATA 1UF
CAPACITOR; SMT (0201); CERAMIC CHIP;
1UF; 10V; TOL=20%; TG=-55 DEGC TO
+85 DEGC; TC=X5R
3 C7 - 1
GRM155R61A106ME44;
GRM155R61A106ME11;
0402ZD106MAT2A
MURATA;MURATA;AVX 10UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
10UF; 10V; TOL=20%; TG=-55 DEGC TO
+85 DEGC; TC=X5R
4 D1 - 1 VEMD5080X01 VISHAY SEMICONDUCTORS VEMD5080X01 DIODE; PIN; SMT; VRM=20V; IR=0.000045A
5 DS1, DS2 - 2 CT DBLP31.12-5C8C-56-J6Q6 OSRAM CT DBLP31.12-5C8C-56-J6Q6 DIODE; LED; GREEN; SMT; VF=2.3V; IF=0.02A ;
6 J1 - 1 5016162575 MOLEX 5016162575
CONNECTOR; FEMALE; SMT; EASY-ON TYPE
FPC CONNECTOR; RIGHT ANGLE; 25PINS
7
R1-R3, R4A-R8A,
R9-R12
- 12 CRCW02010000ZS;ERJ-1GN0R00C VISHAY DALE;PANASONIC 0
RESISTOR; 0201; 0 OHM; 0%; JUMPER;
0.05W; THICK FILM
8 U1 - 1 MAX86140 MAXIM MAX86140
EVKIT PART-IC; OPTICAL AFE OPTIMIZE
FOR HR ON WRIST APPLICATION; WLP20
9 U2 - 1 BMA280 BOSCH BMA280
IC; SNSR; 14 BIT DIGITAL TRIAXIAL
ACCELERATION SENSOR WITH INTELLIGENT
ON-CHIP MOTION-TRIGGRED INTERRUPT
CONTROLLER; LGA12
10 PCB - 1 MAX86140OSB MAXIM PCB PCB:MAX86140OSB -
11 R4B-R8B DNP 0 CRCW02010000ZS;ERJ-1GN0R00C VISHAY DALE;PANASONIC 0
RESISTOR; 0201; 0 OHM; 0%; JUMPER;
0.05W; THICK FILM
TOTAL 28
ITEM REF_DES DNI/DNP QTY MFG PART # MANUFACTURER VALUE DESCRIPTION COMMENTS
1 C1-C5, C10 - 6 GRM155R60J226ME11 MURATA 22UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
22UF; 6.3V; TOL=20%; TC=X5R
2 C7 - 1
GRM155R61A106ME44;
GRM155R61A106ME11;
0402ZD106MAT2A
MURATA;MURATA;AVX 10UF
CAPACITOR; SMT (0402); CERAMIC CHIP;
10UF; 10V; TOL=20%; TG=-55 DEGC TO
+85 DEGC; TC=X5R
3 C8, C9 - 2 GRM033R61A105ME15 MURATA 1UF
CAPACITOR; SMT (0201); CERAMIC CHIP;
1UF; 10V; TOL=20%; TG=-55 DEGC TO
+85 DEGC; TC=X5R
4 DS1 - 1 CT DBLP31.12-5C8C-56-J6Q6 OSRAM CT DBLP31.12-5C8C-56-J6Q6 DIODE; LED; GREEN; SMT; VF=2.3V; IF=0.02A ;
5 J1 - 1 5016162575 MOLEX 5016162575
CONNECTOR; FEMALE; SMT; EASY-ON TYPE
FPC CONNECTOR; RIGHT ANGLE; 25PINS
6 PD1, PD2 - 2 VEMD5080X01 VISHAY SEMICONDUCTORS VEMD5080X01 DIODE; PIN; SMT; VRM=20V; IR=0.000045A
7
R1-R3, R4A-R8A,
R9-R12
- 12 CRCW02010000ZS;ERJ-1GN0R00C VISHAY DALE;PANASONIC 0
RESISTOR; 0201; 0 OHM; 0%; JUMPER; 0.05W;
THICK FILM
8 U1 - 1 MAX86141 MAXIM MAX86141
EVKIT PART-IC; OPTICAL ANALOG FRONT-END
(AFE) OPTIMIZE FOR HR ON WRIST
APPLICATION; WLP20
9 U2 - 1 BMA280 BOSCH BMA280
IC; SNSR; 14 BIT DIGITAL TRIAXIAL
ACCELERATION SENSOR WITH INTELLIGENT
ON-CHIP MOTION-TRIGGRED INTERRUPT CONTROLLER;
LGA12
10 PCB - 1 MAX86141OSB MAXIM PCB PCB:MAX86141OSB -
11 R4B-R8B DNP 0 CRCW02010000ZS;ERJ-1GN0R00C VISHAY DALE;PANASONIC 0
RESISTOR; 0201; 0 OHM; 0%; JUMPER;
0.05W; THICK FILM
TOTAL 28
