MAXPhotonics MFP-20 User Manual

MAXPHOTONICS CO.,LTD
WWW.MAXPHOTONICS.COM
8
Pulse Repetition Rate, kHz 22—70
Nominal Peak Power (pulse energy/FWHM pulse
duration), kW
> 5
Peak Power Instability, % < 5
Residual Pump Power at the Output, dB <-60
OPTICAL OUTPUT
Output Fiber, m
20 / 125 / 3000/7000
Output Fiber Length, m 1.9/2.5/3
Output Collimator Bulk Lens
Output Beam Diameter ( 1/e
2
), mm 6-9
PUMP DIODES
Emission Wavelength, nm 970 +/- 10
Stripe, m
1x100
MTTF ( 20 C ), hours
> 30 000
ELECTRICAL CHARACTERISTICS
Supplied Voltage, V DC 24
Nominal Total Current ( at 24 V, 20 C ), A
< 8,5
Maximum Total Current, A < 15
Typical Power Consumption ( at 20 C ), W
< 140
GENERAL CHARACTERISTICS
Operating Temperature Range, C
0 to (+40)
Storage Temperature, C
(-10) to (+60)
Cooling Method 4 fans
Warm-up Time, s : 10
