Chapter 4
Specification
1-Optical Characteristic Parameters
Characteristics Test conditions Min. Nom. Max. Unit
Mode Pulse
Polarization Random
Beam Quality M
²
Pout=Pnom 1.2 1.45
Center Wavelength Pout=Pnom 1060 1064 1070 nm
Spectrum Width(3dB) Pout=Pnom 8 15 nm
Average Optical
Power(Pnom)
19.5 20 20.5 W
Power Range 10 100 %
Max. Pulse Energy 350ns/33KHz 0.61 mJ
Pulse Width Range 2 350 ns
Optical Pulse
Width(FWHM)
350ns/33KHz 85 ns
Pulse Repetition
Frequency (PRF.)
For Pulse Width
2-40ns
1
1000
(20H)
KHz
For Pulse Width
2-40ns
1
2000
(20S)
KHz
For Pulse Width
50-80ns
1 1000 KHz
For Pulse Width
100-200ns
1 400 KHz
For Pulse Width
250-350ns
1 200 KHz
PRF. Range Under
Full Power
33
1000
(20H)
KHz
33
2000
(20S)
KHz
