MAXPhotonics MFPT-20H - 2-General Characteristic Parameters

16
Chapter 4 Specication
2-General Characteristic Parameters
◎ Note: Beam Diameter and Delivery Cable Length can be customized
against User's specific demand.
Output Power Stability Pout=Pnom 5 %
Beam Diameter 1/e2 6 7 9 mm
Beam Ellipticity 90 %
Delivery Cable Length 1.9 2.5 3 M
Laser startup Time
Pout=Pnom，
10%~90%
300 us
Laser Shutdown Time
Pout=Pnom，
90%~10%
200 us
No. Characteristics Test conditions Min. Nom. Max. Unit
1
Operating
Environment
Tem.
0 40 ℃
2 Storage Tem. -10 60 ℃
3
Cooling
Method
Air-cooling
4 Warm Up Time
Operate 1
min
Stable 10
5
Operating
Environment
humidity
10 95 %
6 Dimensions 264*120*348 mm
7 Weight 11 kg
8 Power Supply 23 24 25 VDC
9
Power
Consumption
Pout=Pnom，
T=20℃
90 120 W
