Chapter 5 Operation Guide
9
Latch(Latches power setting into the laser by the rising edge)
14,15 Ground
24，25 Floating
11，12，16，21 Laser alarms (see alarm codes in the table below).
17 +5±0.25VDC power supply input for pin
16，21
Laser alarms status (see alarm codes in the table below).
18
Master Oscillator(MO) signal
HIGH: MO on
LOW or disconnected: MO off
19
Booster signal (ON/OFF input)
HIGH: Booster on
LOW or disconnected: Booster off
20 Pulse Repetition Rate (Synchronization) input
22
Guide Laser (red diode) ON/OFF input
HIGH: Red diode ON
LOW or disconnected：Red diode OFF
2.PWM (pulse-width modulation)Communication
interface, Control Bus, data timing bus refer to -5.5
Pulse duration Set.
High: OFF
Low: ON/Connect
23
Emergency Stop Input
High: OK (Normal operation)
LOW or disconnected: STOP
