30
Chapter 5 Operation Guide
（1）Set the pulse width, pulse repetition rate, and power according to
different materials and marking purpose.
（2）Cut-off power frequency : If the pulse frequency is lower than the
cut-off power frequency the exact maximum output power will be also
lower than that at the cut-off power frequency. But if the frequency is
higher than the cut-off power frequency, the maximum output power
is the same with that at the cut-off power frequency. For example, the
maximum output power is 20W if the laser is set with 200ns/45KHz/100%,
while the maximum output power is drop to 10W if the laser is set with
200ns/23KHz/100%, and the maximum output power is also 20W if the
laser is set with 200ns/46KHz/100%.
Set Pulse Width （ns） MFPT-20H/MFPT-20S
2 1000
4 630
8 500
10 350
15 200
20 160
30 120
40 100
50 85
60 75
80 68
100 58
125 54
135 50
150 48
160 47
180 46
200 45
220 42
250 40
300 35
350 33
