Maxspect R420R User Manual

11
Operating Instructions
Preset Mode “P”
Under Preset mode, the fixture will be running the following predefined photo-period profiles.
Under Preset mode, the LCD panel will display the current time and time-point. (e.g.
the following diagram illustrates the current time lies between time-point 3 and 4.)
P
1
2
3
4
5
6
A:
100%
B:
100%
1. Press the control dial once to enter setup. Preset #1 will be selected by default.
P
Preset1
S
Preset2
2. Rotate the dial to select the desired preset profile. (e.g. Preset1  Preset2)
P
Preset1
S
Preset2

Maxspect R420R Specifications

General

Model	R420R
Category	Lighting Equipment
Type	LED Aquarium Light
Color Temperature	16000K
Mounting Options	hanging kit optional
Weight	Approx. 6.6 lbs (varies by model)
