Automatic Mode “A”
Under the Automatic mode, users can program their own photo-period profile using 6
Time-Points.
Understanding Time Points
There are a total of 6 Time Points. You can program different luminous output intensity at each
Time Point to control the photoperiod and brightness of the system.
For example, the following table demonstrates how you could program the Time Points such
that the system would increases light gradually from 8:00am, peaks at 10:00am-2:00pm then
slowly decreases light until it is turned off at 10:00pm.
The following diagram would illustrate how the 2 LED channels would behave once the above
Time Points have been programmed.
Setting up Moon Light
Moon-Light can be programmed by simply assign one of the LED channels (preferably the blue
LED channel) to operate at 1% brightness in the last Time Point.
