6
MANUFACTURED BY MAXTEC
2.4 Operation with Optional BC Adapter (refer to figure
below)
1. Attach the included Barbed Adapter to the MAXO
2
+
by threading it on to
the bottom of the sensor.
2. Connect the included tubing to the barbed adapter.
3. Attach the BC adapter (sold separately) to the other end of the tube.
4. Connect the inflator hose on the regulator to the BC adapter and tube.
5. If the MAXO
2
+
is not already turned on, do so now by pressing the
analyzer “ON” button.
6. Initiate flow of nitrox to the unit to allow the gas to saturate the sensor. The
BC adapter will regulate the optimum flow and pressure. Although a stable
value is usually observed within 30 seconds, allow at least two minutes to
ensure that the sensor is completely saturated with the gas.
7. The analyzer will now look for a stable sensor signal and a
good reading. When obtained, the analyzer will display
the oxygen percentage on the LCD.
FIGURE 3
Inflator Hose
Nitrox Tank
To Next Page
