contain salt, which can accumulate in the sensor membrane and impair
readings.
Accessories
• The threaded barbed adapter may be cleaned by washing them with a
65% alcohol/water solution (per manufacturer’s instructions). The parts
must be thoroughly dry before they are used.
Because of the variability of the cleaning processes, Maxtec cannot provide
specific instructions. Therefore, we highly recommend referring to the manu-
facturer’s instructions on the details of method.
9.0 SPECIFICATIONS
9.1 Base Unit Specifications
Measurement Range: 0-100%
Resolution: 0.1%
Accuracy and Linearity: 1% of full scale at constant temperature, R.H. and
pressure when calibrated at full scale.
Total Accuracy: ±3% actual oxygen level over full operating
temperature range.
Response Time: 90% of final value in approximately 15 seconds at
23°C.
Warm-up Time: none required
Operating Temperature: 15°C - 40°C (59°F - 104°F)
Storage Temperature: -15°C - 50°C (5°F - 122°F)
Humidity: 0-95% (non-condensing)
Power Requirements: 2, AA Alkaline batteries (2 x 1.5 Volts)
Battery Life: approximately 5000 hours with continuous use
Low Battery Indication: “BAT” icon displayed on LCD
Sensor Type: Maxtec MAX-250 galvanic fuel cell
Expected Sensor Life: >1,500,000 O
2
percent hours minimum 2-years in
typical applications
A Model Dimensions: 3.0”(W) x 4.0”(H) x 1.5”(D) [76mm x 102mm x
38mm]
A Weight: 0.4 lbs. (170g)
AE Model Dimensions: 3.0”(W) x 36.0”(H) x 1.5”(D) [76mm x 914mm x
38mm] Height includes external cable length
(retracted).
AE Weight: 0.6 lbs. (285g)
13
