Maxx Cold MCF-23FD - Reversible Door Installation; Re-installing Top Grill and Grill Assembly

3. Installation method of REVERSIBLE DOOR
4. Installing TOP GRILL and GRILL ASSEMBLY
1) Install the screws
at the location ῡ
on the top and bottom
of the top grill.
2) Install the screws
at the location ῢ
on the left and right
side of the grill
assembly.
1) After reversing 180 degree DOOR ASSEMBLY ῦ, locate the HANDLE in the
desired side.
2) Assemble in the following
order.
- After assembling ΰῢL assemble ῤῥ
- Insert into ῤ DOOR ASSEMBLY of ῦ
- After inserting ῧῨ, secure ΰῩ
- Insert reversible for suitable spring elasticity
# Attention : Securely tighten all fastners.
Ῡ M5*27 SCREW
ΰ DOOR-HINGE
LOWER
Ῠ DOOR-HINGE
SHAFT-LOWER
ῦ DOOR ASSEMBLY
ῥ DOOR-HINGE BUSHING
ῡ DOOR-HINGE STOP PIN
ΰ DOOR-HINGE UPPER
ῢ M5*27 SCREW
ῤ DOOR-HINGE
SHAFT-UPPER
ῧ DOOR-HINGE
BUSHING
ῡ
ῢ
PICTURE C
PICTURE D
