CONTENTS
SERIAL NUMBER
1. SPECIFICATIONS
2. SERIAL NUMBER
3. INSTALLATION
4. CLEANING
5. CAUTION
6. BASIC OPERATION
6-1. REFRIGERATOR
6-2. FREEZER
7. TROUBLE SHOOTING GUIDE
The serial number is located on the rating label which is on the left interior wall.
Please retain the unit's serial number for service purposes.
2
2
3
4
4
5 - 6
7 - 8
9
SPECIFICATIONS
Solid Door Refrigerators
MODEL COMP. H.P REFRIGERANT AMPS WEIGHT
MCR-23FD, MCR-23FDRE
1/3 R-134a 6.0 A 271 LBS
MCR-49FD, MCR-49FDRE
1/3 R-134a 7.0 A 370 LBS
MCR-72FD, MCR-72FDRE
3/4 R-134a 10.3 A 507 LBS
Solid Door Freezers
MODEL COMP. H.P REFRIGERANT AMPS WEIGHT
MCF-23FD, MCF-23FDRE
1/3 R-134a 7.0 A 284 LBS
MCF-49FD, MCF-49FDRE
3/4 R-404A 11.8 A 403 LBS
MCF-72FD, MCF-72FDRE
1/2 R-404A 9.2 A 560 LBS
Glass Door Refrigerators
MODEL COMP. H.P REFRIGERANT AMPS POUNDS
MCR-23GD 1/3 R-134a 6.5 A 295 LBS
MCR-49GD 3/4 R-134a 11.5 A 460 LBS
