BASIC OPERATION
1. Plug in and turn on the power switch located on the bottom of the top grill.
The Display panel will be lighted. The compressor will begin to run.
2. The default temperature setting is -2ᵻ (-19ᴱ)
3. The compressor is automatically cycled by the electronic controller (PCB,
D-sensor).
4. The Defrost cycle is automatically controlled by the D-sensor and the PCB.
5. Temp. Control range 5ᵻ@-9ᵻ (-15ᴱ@-23ᴱ)
6. The interior light is activated by the door switch at the bottom of the grill when the
door is opened.
7. Evaporator fan motor(s) will run after all doors are completely closed.
MCF-23FD, MCF-23FDRE
MCF-49FD, MCF-49FDRE
MCF-72FD, MCF-72FDRE
FREEZER
