SPECIFICATIONS
SOLID DOOR REFRIGERATORS
Model
Number
V/Hz/Ph AMPS
STORAGE
CAPACITY
Cu-ft
HP
SHELF
CAPACITY
Sq-ft
BTU REFRIGERANT
CHARGE
OZ
NEMA
PLUG
MXCR-19FDHC 115/60/1 8 19 1/3 9.5 3200 R290 3.0 5-15P
MXCR-23FDHC 115/60/1 6 23 3/8 14.0 3200 R290 3.0 5-15P
MXCR-49FDHC 115/60/1 9 49 1/2 28.1 5800 R290 3.7 5-15P
MXCR-72FDHC 115/60/1 10 72 3/4 42.1 7625 R290 5.29 5-15P
2
SOLID DOOR FREEZERS
Model
Number
V/Hz/Ph AMPS
STORAGE
CAPACITY
Cu-ft
HP
SHELF
CAPACITY
Sq-ft
BTU REFRIGERANT
CHARGE
OZ
NEMA
PLUG
MXCF-19FDHC 115/60/1 3
19
5/8 9.5 2325 R290 3.88 5-15P
MXCF-23FD 115/60/1 11
23
5/8 14.0 2325 R404 14.1 5-15P
MXCF-49FD 115/60/1 12 49 1 28.1 3650 R404 25 5-15P
MXCF-72FD 115/208 - 230/60/1 8 72 1-1/4 42.1 4500 R404 28.9 L14-20P
