Maxx Cold MXM1-12RB - Specifications

SPECIFICATIONS
SWING GLASS DOOR REFRIGERATORS
Model
Number
V/Hz/Ph AMPS
STORAGE
CAPACITY
Cu-ft
HP
CHARGE
OZ
SHIP
WEIGHT
LBS
NEMA PLUG
MXM1-12R 115/60/1 6 12 3/8 12.0 254 5-15P
MXM1-16R 115/60/1 6 16 3/8 12.0 282 5-15P
MXM1-23R 115/60/1 6 23 3/8 12.0 331 5-15P
MXM2-48R 115/60/1 7 48 1/2 18.7 540 5-15P
MXM3-72R 115/60/1 10 72 3/4 21.2 741 5-15P
SWING GLASS DOOR FREEZERS
Model
Number
V/Hz/Ph AMPS
STORAGE
CAPACITY
Cu-ft
HP
CHARGE
OZ
SHIP
WEIGHT
LBS
NEMA PLUG
MXM1-12F 115/60/1 11 12 3/8 10.6 258 5-15P
MXM1-16F 115/60/1 11 16 5/8 11.3 289 5-15P
MXM1-23F 115/60/1 11 23 5/8 14.1 353 5-15P
MXM2-48F 115/208 - 230/60/1 8 48 1 25.0 567 L14-20P
MXM3-72F 115/208 - 230/60/1 11 72 1-1/4 28.9 829 L14-20P
SLIDING GLASS DOOR REFRIGERATOR
Model
Number
V/Hz/Ph AMPS
STORAGE
CAPACITY
Cu-ft
HP
CHARGE
OZ
SHIP
WEIGHT
LBS
NEMA PLUG
MXM2-48RS 115/60/1 7 48 1/2 18.7 540 5-15P
SERVICE AND INSTALLATION MANUAL
www.maxximumfoodservice.com
2
