Maxx Ice MIM250 - Component Identification List

12
Item No.
Description
2
Ice scoop
3
Top panel
7
Drain nut
9
Condenser
10
Hot gas valve body (EVU3)
11
Hot gas valve coil（042N4212）
16
Compressor
17
Compressor starting device component
18
Water trough
22
Floater valve
23
water inlet pipe screw
24
Drain valve
25
Water out tube of pump
26
Water pump
27
Water inlet
28
Condenser sensor
29
Evaporator sensor
31
Water sprinkler
32
Evaporator (Ice Mold)
33
Ice slideway
35
Wiring harness
36
Magnetism switch
38
Power plug
41
EBM motor 5W
42
Fan blade (φ200X28°)
43
EBM motor 10W
49
Power switch
50
Clean switch
51
Under louver
52
Door
54
Locked screw(Block screw)
55
Foot
57
Drier
60
15A fuse of controller
61
Control box
