Maxx Ice MIM452 - Parts List and Descriptions

13
ITEM
NO.
DESCRIPTION
1
front panel
2
inner front panel
3
Ice full probe
4
inner foam front panel
5
Ice full sensor
6
evaporator
7
water trough
8
front inner right panel
9
back inner right panel
10
right panel
11
Floater valve
12
support
13
fan motor capacitor (6uf)
14
Condenser fan motor
15
fan motor support
16
Water inlet pipe
17
Water outlet pipe screw
18
water outlet pipe screw
19
Water inlet connector
20
foaming PE
21
top panel
22
compressor starting device
component
23
compressor
24
discharge pipe1
25
suction pipe
26
condenser and filtrate
27
T shape three ways
28
hot gas valve body
29
Cu Three ways
30
Has gas valve coil
31
hot gas pipe
32
Condenser sensor line
33
hot gas pipe
34
discharge pipe2
35
Expansive valve
36
drier
37
protect line cord
38
access cover
39
back panel
40
Power switch
41
Wiring harness
42
Control box
43
15A fuse
