■ Do not use any multiple sockets,
extension cables more than 3 m long
or cable extension reels.
■ Check the device, the connecting
cable and all accessories for damage
prior to installation. Use the device
only if all components are undamaged
and in working order.
Outlet Pipe
The items supplied include a fl exible out-
let pipe(2) and a standard outlet pipe(7).
If the fl exible outlet pipe is to be used,
fi rst of all the cover(8) must be removed
from the standard outlet pipe and
plugged onto the fl exible outlet pipe.
The procedure is shown in PictureF.
Once the cover is attached to the outlet
pipe you want, proceed as follows:
1. Make sure that the sealing ring is
properly attached to the thread(15) of
the main device(1).
2. Plug the outlet pipe up to the white
plastic sleeve into the outlet pipe
connection(10) (PicturesC and D). Do
not damage the rubber sealing rings
on the outlet pipe!
3. Screw the cover to the thread of the
main device (PictureE).
Main Device
The connecting cable(14) can be laid
above or below the installation surface(b)
(sink or worktop).
Above the installation surface
(Picture G)
The diameter of the hole in the installa-
tion surface must be 2 to 5,8 cm.
1. Place the spacer ring(3) (with the
closed surface facing upwards) onto
the threaded pipe(13) of the main
device(1).
2. Insert the connecting cable into the
slot in the spacer ring.
3. Place the spacer ring(4) onto the
threaded pipe, the connecting cable
remains outside the sealing ring.
4. Place the threaded pipe into the hole
in the installation surface.
5. Under the installation surface, place
the cable guide ring(5) (with the
closed surface facing downwards)
onto the threaded pipe.
6. Screw the locking nut(6) onto the
threaded pipe and tighten it.
Below the installation surface
(Picture H)
The hole in the installation surface must
be suffi ciently large that the mains plug
(Ø 3.8 cm) of the connecting cable fi ts
through it. However, its diameter must
not be larger than 5.8 cm (Ø of the main
device).
1. Place the mains plug through the seal-
ing ring(4) and slide the sealing ring
over the threaded pipe(13) as far as
the main device.
2. Place the threaded pipe and the
connecting cable into the hole in the
installation surface.
3. Under the installation surface, place
the cable guide ring(5) or the spacer
ring(3) (with the closed surface facing
downwards) onto the threaded pipe
and lay the connecting cable in the
slot.
4. Screw the locking nut(6) onto the
threaded pipe and tighten it.
