Electric Stainless Steel Fitting
EN
9
LIST OF CONTENTS
Items Supplied 9
At A Glance 9
Symbols 10
Signal Words 10
Intended Use 11
Safety Notices 11
Assembly 12
Setting the Water Temperature 14
Cleaning and Maintenance 14
Troubleshooting 15
Disposal 15
Technical Data 16
ITEMS SUPPLIED
(Picture A)
1 Main device with connecting cable 1 x
2 Flexible outlet pipe 1 x
3 Spacer ring 1 x
4 Sealing ring 1 x
5 Cable guide ring 1 x
6 Locking nut 1 x
7 Standard outlet pipe 1 x
8 Cover 1 x (fi tted on the standard
outlet pipe)
9 Storage bag 1 x (for the main device)
• Assembly and operating instructions
1 x
A water hose with a hose screw
connection or an adapter with a
½“ internal thread is also re-
quired. Which connection piece
is required between the hose and
the water pipe depends on the
respective water pipe.
Check the items supplied for complete-
ness and the components for transport
damage. If you fi nd any damage, do not
use the device but contact our customer
service department.
Remove any possible fi lms, stickers or
transport protection from the device.
Never remove the rating plate and any
possible warnings!
AT A GLANCE
(Picture B)
10 Outlet pipe connection
11 Display
12 Lever
13 Threaded pipe
14 Connecting cable
15 Thread with sealing ring
