4
Part Description QTY
5 "Hexagon socket button head bolt
M10x65"
10
6 washer Ø10 28
7 lock nut M10 15
8 "hexagon socket button head bolt
M10x70"
2
18 corrugated washer Ø10 2
20 hexagon socket button head bolt
M10x25
1
21 hexagon screw
M10x30
2
22 spring washer Ø10 2
23 curved washer Ø10 2
27 hexagon socket button head bolt
M8x40
4
28 washer Ø8 8
37 hexagon socket button head bolt
M8x25
4
38 hexagon socket button head bolt
M10x75
1
42 hexagon socket button head bolt
M8x20
4
Fixing Material
