WHEN CHARGING IS COMPLETE
Switch off the mains supply, unplug the charger and disconnect the clips in the following order:
Remove the negative (BLACK lead) first. Then disconnect the positive (RED lead) from the battery.
TROUBLE SHOOTING
Switch off the charger, check that the clips are correctly connected to the battery and making a good contact.
Check the output fuse situated on the positive output lead of the charger (reverse polarity connection will
cause this to blow). The only other user serviceable part is the mains fuse fitted inside the mains plug. The
battery must be in good condition and capable of accepting a charge. Check that the mains supply is
connected, switch “ON” the charger and check that the red “25%” led is illuminated.
TECHNICAL SPECIFICATIONS
We declare that this product conforms to the following standards EN60335-1,
EN60335-2-29, EN55014, EN61000, and the following Directives 73/23 CEE, 93/68 CEE,
2004/108/EC, 2002/95/EC (ROHS)
Technical Manager Maypole Ltd May 2017
email: sales@maypoleltd.co.uk
web: www.maypole.ltd.uk
